Servohydraulic compact systems

Test load

10 kN - 100 kN

Type of test

Fatigue
Fracture mechanics
LCF

Standards

ISO 12106
ASTM E606
DIN 50100
ASTM E399
ASTM E647
ASTM E466

Description Videos Benefits Technical overview Expanded temperature range Software

Compact testing system with hydraulic power pack

The HC series compact testing system is a complete testing system in which the low noise power pack serves as the substructure for the test frame, keeping the machine’s footprint to a minimum. Combined with special sound insulation for the hydraulic power pack, the HC Compact is ideal for operation in a laboratory.

The HC Compact testing machine is available in two sizes.

The HC Compact 10/25 kN is designed for fatigue tests on smaller components, down to and including biomedical tests. The machine is equipped with a T-slotted platform and the testing actuator is therefore located in the upper crosshead.
The HC Compact 50/100 kN is adapted for a full range of accessories for tests on composites, with which both static and dynamic testing can be performed. Due to the high stiffness of the load frame and easy connection of a high-temperature furnace, this machine is also optimally suited for LCF tests.

A temperature chamber can be installed on both models without a lot of effort. For applications with particularly high requirements on the load string alignment (e.g. LCF tests) the machines can be equipped with an optional alignment fixture.

Videos on the servohydraulic compact testing system

By playing this video, you agree to the use of cookies as well as to the transfer of data to YouTube in the USA. Additional data privacy notices.

Fatigue test on control arms

The HC25 compact testing system is used for application of a fatigue load on the control arms. The power pack is part of the machine and does not require an external hydraulic supply.

By playing this video, you agree to the use of cookies as well as to the transfer of data to YouTube in the USA. Additional data privacy notices.

Low cycle fatigue test

An HC100 servohydraulic compact testing system with high-temperature furnace is used for the determination of low cycle fatigue under high temperature to ASTM E606.

Advantages and features

Minimum space requirement

The low noise power pack forms the base support for the test frame, reducing the machine’s footprint to a minimum.

With a total weight of approximately 1,200 kg (HC Compact 10/25) and approx. 1,400 kg (HC Compact 50/100), it can be set up on almost any industrial floor.

Low volume

Because of the integrated low noise power pack design, no additional sound insulation measures of any type are required. The HC Compact can therefore be set up in almost any laboratory.

Closed force distribution

The two-column test frame is bolted directly to the hydraulic power pack. The entire testing system, including the hydraulic power pack, stand on anti-vibration leveling elements.

Alignment accuracy

The servohydraulic compact testing systems are aligned with utmost precision. After installation of the testing actuator and load cell, the alignment accuracy is +0.1 per meter distance. At a distance of less than 350 mm, the offset is a constant 0.05 mm. Plane-parallelity of the mounting surfaces is equal to or better than 0.03 mm per 100 mm.

All fixtures and load cells are mounted via flanges with a centering gauge.

Remote control

The entire test, including setup and control of automatic extensometers and specimen grips, is run via the display-equipped remote control.

Operator protection

Regardless of application, we offer an optional safety housing in compliance with the CE Machinery Directive.

Crosshead adjustment

Hydraulic adjustment for easy positioning of the upper crosshead is available as an option.

Hydraulic power pack cooling system

In addition to water cooling, the hydraulic power pack of the HC Compact 50/100 has an internal cooling circuit, which reduces the escape of heated air from the hydraulic power pack to a minimum. Therefore, there is much less heat in the room and the testing system can be set up in almost any laboratory.

Hydraulic power pack maintenance

The hydraulic power pack is easily accessible for maintenance tasks.

On the HC Compact 10/25, the power pack can be easily removed from the side via guide rails.

On the HC Compact 50/100, side panels and the cover for the hydraulic power pack can be removed in a few simple steps. All relevant components are arranged in such a way that they can be easily accessed be service personnel.

Technical overview

Compact testing system HC25 Compact — Comparison of compact testing systems

Compact testing system HC100 Compact — Comparison of compact testing systems

	HC Compact 10/25	HC Compact 50/100

Force levels	10 kN 25 kN	50 kN 100 kN
Power rating	12 lpm	30 lpm
Testing actuator	Upper crosshead	Lower crosshead
T-slotted platform	✓	✓
Temperature chamber	-	✓
High-temperature furnace	-	✓
Alignment fixture	✓	✓
Typical Applications	Components Biomedicine	Composites LCF tests

Test area height	Standard	Extended by 250 mm¹	Extended by 500 mm
Dynamic nominal force	25	25	25	kN
A - max. height of end of column	2240	2490	2740	mm
A_G100 – max. height with 100mm testing actuator	2725	2975	3225	mm
A_G250 – max. height with 250mm testing actuator	3025	3275	3525	mm
B - max. width	720	720	720	mm
C - max. depth	1360	1360	1360	mm
F - height of top edge of lower crosshead	995	995	995	mm
K - total weight²	1080	1095	1120	kg
C1 – max. depth of test frame	450	450	450	mm
D1 - distance between columns	460	460	460	mm
E – column diameter	65	65	65	mm
G – max. test area height³	1070	1320	1570	mm
H – max. working test area height⁴	310 to 1010	560 to 1260	810 to 1510	mm
Frame stiffness at 1000mm crosshead separation	300	300	300	kN/mm
T-slots	as per DIN 650 12H12, spacing 80 mm
Connection size	Ø 70 mm, 6 x M8 and Ø 115 mm, 4 x M8
Clamping/ adjustment: manual/manual	1037238	1037462	1037469
Clamping/ adjustment: manual/hydraulic	1036930	1036931	1037473

Required for use with temperature chamber
With oil and 100mm testing actuator, no grips
Distance between upper and lower crossheads
Distance between piston flange and lower crosshead with piston retracted

Test area height	Standard	Extended by 500 mm¹
Dynamic nominal force	50/100	50/100	kN
A – max. height of end of column	2320	2820	mm
(with alignment fixture)	(2430)	(2930)	mm
B – max. width	860	860	mm
C – max. depth	2000	2000	mm
D1 – distance between columns	445	445	mm
E – column diameter	80	80	mm
F – height of top edge of lower crosshead	872	872	mm
G – max. height of test area²	350 ... 1175	600 ... 1680	mm
K – total weight³	1700	1750	kg
Frame stiffness at 1000 mm crosshead separation	500	500	kN/mm
Connection dimension	Ø 105 mm, 12 x M10
HC 100 – clamping/adjustment: hydraulic/hydraulic	1085595	1085611
HC 50 – clamping/adjustment: hydraulic/hydraulic	3010277	3010276

Required for use with temperature chamber
Distance between piston flange and lower crosshead with piston retracted
With oil and 100 mm testing actuator, no grips

Noise level	<58	dB(A)
System pressure	210	bar
Nominal output	10.7	l/min
Volume, oil reservoir	160	l
Coolant water req. max.	5	l/min
Cooland water inlet temperature	15 … 28	°C
Emitted heat	0,8	kW
Electrical supply	400, 3PH/N/PE, 50 Hz¹	V
Motor power rating	5	kW
Weight with oil	690	kg
Item No.	1036929

Or: 440 V, 3PH/N/PE, 60 Hz

Noise level	<58	dB(A)
System pressure	280	bar
Nominal output	30	l/min
Volume, oil reservoir	160	l
Coolant water req. max.	30	l/min
Cooland water inlet temperature	15 … 28	°C
Emitted heat	0,5	kW
Electrical connection	400, 3PH/N/PE, 50 Hz¹	V
Motor power rating	15	kW
Item No.	3009244

Or: 440 V, 3PH/N/PE, 60 Hz

Do you have any questions regarding our products?

Please feel free to contact our product experts.
We look forward to discussing your needs.

Testing in an extended temperature range

The servohydraulic HC50/100 compact testing system is particularly suitable for use at elevated temperatures thanks to the testing actuator mounted in the lower crosshead. Tests in different temperature ranges are used to determine the effect of specific temperatures on material properties. For these tests, ZwickRoell offers various temperature chambers and high-temperature furnaces that guarantee the perfect solution for every application.

Temperature chambers are mainly used in low cycle fatigue tests (LCF tests) to investigate the effects of thermal stress on the fatigue behavior of materials. Testing temperatures up to 1,000 °C are not uncommon when it comes to LCF tests.

Since composites are often used in components that are subject to thermal stress, testing is also carried out in the elevated temperature range. For static and dynamic composites testing, the load frame also features a particularly stiff design and can be equipped with an optional alignment fixture. All relevant static test fixtures for composites can be integrated in the machine. This makes it the composites testing machine par excellence.

Servohydraulic compact testing system with temperature chamber

testXpert R – our software for dynamic testing

testXpert R is used with servohydraulic testing machines, vibrophores and electrodynamic testing machines. The testing software offers the right test programs for fatigue tests, fracture mechanics, low cycle fatigue (LCF). A graphical block editor is available for free test configurations, where up to 100 blocks can be parameterized.

Learn more about the testXpert R testing software

Other dynamic testing machines

Typical tests for servohydraulic compact systems

Metals | Low cycle fatigue test (LCF)

ISO 12106, ASTM E606

to Metals | Low cycle fatigue test (LCF)

Metals | Fatigue test (S-N curve test)

DIN 50100

to Metals | Fatigue test (S-N curve test)
